Crossfire X600 ATV
Crossfire X600 ATV
The full-size Crossfire X600 comes equipped with a fuel injected 546cc Engine and 4-wheel drive giving you the ability to tackle the toughest trails. The X600 is the most powerful quad in the Crossfire stable. The power for towing, the torque for working and a smooth effortless feel that will handle all terrain.
The Dual A-Arm Nitrogen Assisted Shocks give the Crossfire 600 a smooth unforgettable ride. The X600’s front and rear cargo racks and locale front differential and if all else fails a 2500LB Winch make it the right choice for your off-road adventure.
The fully automatic gear box with low range and high range transfer case are standard and electric power steering comes in handy in rough conditions acting as a damper against the bumps while providing assistance in the tight corners.
The minimum standard to pass the lateral stability tilt angle test is 28.81 degrees. The Crossfire X600 exceeds the minimum lateral stability tilt angle test with a result of 32.7 degrees.
With the introduction of the Quad bike safety standard, all Crossfire General use machines come standard with the Quad Bar Flexi inside every carton. Your dealer will fit this to the machine before pick up. It mandatory for all our dealers to fit this CPD safety device in order to improve safety and comply with the Quad bike safety standard.
Standard Features:
- Electronic fuel injection
- Winch 2500lb
- 4×4 Dual Range
- Differential Lock
- Tow Hitch
- 6Ply tyres
- Power Steering
- Quad Bar CPD included
Specifications | |
---|---|
Engine | 4-stroke SOHC |
Displacement | 546cc |
Power | 30 HP @6000rpm |
Torque | 40 N.m @5000rpm |
Drive | 2WD / 4WD Shaft |
Cooling | Liquid |
Carburettor | EFI |
Starter | Electric |
Ignition | ECU |
Transmission | CVT L-H-N-R-P |
Clutch | Wet multi-plate |
Compression ratio | 9.5 : 1 |
Bore x stroke | 91 × 84 mm |
Fuel capacity | 17 L |
Suspension front | Dual A-Arm, hydraulic w/ nitrogen assist |
Suspension rear | Dual A-Arm, hydraulic w/ nitrogen assist |
Wheelbase | 1447 mm |
Brakes front | Dual Disc |
Brakes rear | Disc |
Rims | 12″ steel |
Tyres front | 25 x 8-12 |
Tyres rear | 25 x 10-12 |
Dimensions (L x W x H) | 2286 x 1193 x 1384 mm |
Seat height | 930 mm |
Ground clearance | 279 mm |
Empty vehicle weight (EVW) | 390 kg |
Max rider and cargo weight | 288 kg |
Towing capacity | 544 kg inc rider |
Winch | 1100 kg |
Cargo racks | Front & rear |
Passenger backrest | Standard |
Warranty | |
---|---|
12 months up to 24 months* | * If 1 month and 6 months services have been done by a Crossfire Dealer – warranty is extended to 2 years for vehicles 250cc and up. Please make sure you have proof of services. |
